gmc gantry machining center 5027
detailed introduction:

technical parameter:


modelunitgmc5027a
workbench
workbench (length * width)mm5000*2300
workbench z maximum loadkg18000
t-slot (number of slots * slot width * pitch)mm11-22*200
processing range
door widthmm2700
x-axis/y-axis/z-axis/strokemm5200/2700/1000
distance from spindle end face to work tablemm310-1310
feed system
cnc system
fanuc oi mdfanuc 3g
rapid displacement of x/y/z axism/min12/12/10
z maximum cutting feed ratem/min7
automatically switch to the system (cnc milling does not have this option)
number of standard tools (pieces)
bt50/32
tool z large knife warp / lengthmmφ125/300
tool exchange method
气动
z-large tool weightkg18
precision
positioning accuracymm0.021
repeatabilitymm0.02
rail form
x-axis guide
roller linear guide
y-axis guide
roller linear guide
z-axis guide
rectangular rail
spindle system
spindle specifications (model/installation diameter)
bt50/φ200
spindle speedr.p.m4000
spindle motor powerkw22/26
air pressure
air demandkg/cm²6
air source flowm³/min0.5
machine specifications
machine weightkg51000
dimensions (l*w*h)mm11840*5150*4850
